RUGGEDCOM WIN
User Guide
Chapter 5
Setup and Configuration
Configuring the Access List 89
Figure85:Access List Screen
1.Add 2.Delete
2. Configure the following parameter(s) as required:
Parameter Description
Access List Synopsis: { Enable, Disable }
Displays the setting for the Access List.
Total Number of Entries Displays the number of entries.
Max Number of Self-Learned Entries Default: 1
Displays the maximum number of Self-Learned Entries
3. Configure the following parameter(s) as required:
Parameter Description
MAC Address Displays the MAC Address.
Status Synopsis: { Sticky, Non-Sticky }
Displays the Status. Sticky addresses remain in the table after a
reboot. Non-Sticky addresses are cleared from the table after a
reboot.
Type Synopsis: { Self-Learned, Preprovisioned }
Displays Self-Learned Entries.
4. Click Apply.
