Chapter 5
Setup and Configuration
RUGGEDCOM WIN
User Guide
52 Managing Connectivity with Base Stations
NOTE
Additional parameters can be configured remotely through the wireless link.
1. Connect a computer to the device and log in to the management interface. For more information, refer to
Section2.2, “Logging In” .
2. Configure the scanner and connect to the base station. For more information, refer to Section5.2.1,
“Configuring the Scanner” .
3. Configure the IP address for the device. For more information, refer to Section5.14, “Configuring Network IP
Addresses” .
4. Verify the device is operational. This can be done by reviewing the statistics. For more information, refer to
Section3.3.1, “Viewing General Statistics” .
5. View the service flow information and make sure the service flows are created. For more information, refer to
Section3.3.4, “Viewing and Clearing Service Flow Statistics” .
6. Log out of the management interface. For more information, refer to Section2.3, “Logging Out” .
Section5.2
Managing Connectivity with Base Stations
This section describes how to connect to and disconnect from the base station.
CONTENTS
• Section5.2.1, “Configuring the Scanner”
• Section5.2.2, “Deleting Scanner Configurations”
• Section5.2.3, “Connecting to the Base Station”
• Section5.2.4, “Disconnecting from the Base Station”
• Section5.2.5, “Viewing Base Station Information”
Section5.2.1
Configuring the Scanner
Use the scanner to set the Carrier to Interference + Noise Ratio (CINR) threshold value and define the scanning
frequencies for the device. The device uses this information to scan for and locate available base stations.
During the scan, the device builds a table of detected base stations. If the device finds a base station with a CINR
greater than the user-defined threshold, it stops the scan and connects to the base station immediately. This
technique reduces scanning time.
The Scanner Table lists the frequencies scanned by the device to locate its base station.
The Scan Report field displays a list of base stations located by the scan. The list includes the following
information for each base station:
• the base station ID
• the base station frequency
• the base station bandwidth
