Siemens RUGGEDCOM WIN5123 User Manual

Chapter 5
Setup and Configuration
RUGGEDCOM WIN
User Guide
82 Configuring DSCP Marking
Parameter Description
sysUpTime Displays the length of time, in hundredths of a second, since the
SNMP subsystem was last initialized.
Contact Details Contains subscriber station contact information including name
and contact details.
Subscriber Station Name Displays the subscriber station name.
Street Address Contains the subscriber station street address or location
sysServices Displays a value indicating the set of services provided by the
system. The value 2 indicates the datalink/subnetwork layer.
3. Click Apply.
Section5.13
Configuring DSCP Marking
To configure Differentiated Services Code Point (DSCP) marking (identified outgoing management traffic), do the
following:
1. Navigate to Management» Remote Management» DSCP Marking. The DSCP Marking screen appears.
Figure77:DSCP Marking Screen
2. In the DSCP marking [0-63] parameter, type a value in the range of 0 to 63. The default value is 48.
3. Click Apply.
Section5.14
Configuring Network IP Addresses
To configure the LAN and RF IP addresses for the device, do the following:
NOTE
• Use the LAN IP address when you access the SS through a direct connection to its physical Ethernet
port.
• Use the RF IP address when you access the SS through the RF network.
1. Navigate to Network. The IP Settings screen appears.
