Siemens SIMATIC NET System Manual

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
147
4.5.8.2 Features
The individual devices have the characteristics shown in the following table:
XB108-2
XB112
XB116
XB124
Gigabit Ethernet
-
Power supply 24 V DC / 24 V AC
Redundant power supply
●
Diagnostics LED ●
● Suitable / available or according to the specified standard
4.5.8.3 Interfaces
Device
Twisted pair
Fiber-optic cables
10/100 Mbps
10/100 Mbps
Max. segment length / km
XB108-2 (SC)
8x RJ45
2x SC, multimode
5*
XB108-2 (ST)
8x RJ45
2x ST/BFOC, multimode
5*
XB112
12x RJ45
-
-
XB116
16x RJ45
-
-
XB124
24x RJ45
-
-
* With a cable cross-section of 50/125 μm or 62.5/125 μm; attenuation ≤ 1 dB/km at
1310 nm; 1200 MHz * km
4.5.8.4 Article numbers
Device
Description
Article number
SCALANCE XB108-2(SC) 8x 10/100 Mbps RJ45 ports, 2x
10/100 Mbps SC ports, multimode fiber-
optic cable
6GK5108-2BD00-2AB2
SCALANCE XB108-2(ST) 8x 10/100 Mbps RJ45 ports, 2x
10/100 Mbps ST/BFOC ports, multimode
fiber-optic cable
6GK5108-2BB00-2AB2
SCALANCE XB112
12x 10/100 Mbps RJ45 ports
6GK5112-0BA00-2AB2
SCALANCE XB116
16 x 10/100 Mbps RJ-45 ports
6GK5116-0BA00-2AB2
SCALANCE XB124
24 x 10/100 Mbps RJ45 ports
6GK5124-0BA00-2AB2
