SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
155
All ECC versions of the device are approved for railway applications according to EN 50155
and EN 50121-4.
4.5.12.2 Features and functions
Features
The individual devices have the characteristics shown in the following table:
Redundant power supply ●
On site display (Set button) ●
● Suitable / available or according to the specified standard
Functions
All devices have the following functions:
● Configuration with the Primary Setup Tool (PST) V3 or higher;
to use the Primary Setup Tool to assign the IP address, the switches must be accessible
via Ethernet.
● Configuration of the IP address with DHCP
● Web Based Management
● Command Line Interface
● HTTP, HTTPS
● SNMP
● SNTP
● MIB support
● TRAPs via e-mail
● Ring redundancy (not for 6GK5204-0BS00-3PA3/6GK5204-0BS00-3PA3)
● RNA (PRP)
