SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
177
● MRP interconnection
● STP/RSTP (Spanning Tree Protocol/Rapid Spanning Tree Protocol) as well as RSTP+
● Passive listening
● Topology support (LLDP)
● VLAN (Virtual Local Area Network) port based
● IGMP Snooping/Querier (Internet Group Management Protocol)
● DHCP server / DHCP client / DHCP options 66, 67, 82
● Access Control List (ACL), MAC and IP-based
● IEEE 802.1x (radius)
● Link aggregation
● PROFINET diagnostics
● Some devices exist in two variants: PROFINET and EtherNet/IP However, the mode can
be switched over as required for both device variants.
In EtherNet/IP mode, the devices also have EtherNet/IP diagnostics.
4.5.17.3 Interfaces
10/100/1000 Mbps with PoE
XP208
XP208 EEC
8x M12 - - -
XP216
XP216 EEC
12x M12 - 4x M12 -
4.5.17.4 Article numbers
Article number
(PROFINET)
Article number
(Ethernet/IP)
SCALANCE XP208 8x 10/100 Mbps M12 connector tech-
6GK5208-0HA00-2AS6 6GK5208-0HA00-2TS6
SCALANCE XP208 EEC 8x 10/100 Mbps M12 connector tech-
nology electrical, coated PCB
6GK5208-0HA00-2ES6 -
SCALANCE XP208PoE EEC 8x 10/100 Mbps M12 connector tech-
nology electrical, coated PCB, Power
6GK5208-0UA00-5ES6 -
SCALANCE XP216 12x 10/100 Mbps and 4x
10/100/1000 Mbps M12 connector
6GK5216-0HA00-2AS6 6GK5216-0HA00-2TS6
