SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
160 System Manual, 09/2019, C79000-G8976-C242-10
4.5.13.3 Interfaces
Device
Twisted pair
Fiber-optic cables
10/100 Mbps
10/100 Mbps
Max. segment length / km
XB208
8x RJ45
-
-
XB205-3 (SC)
5x RJ45
3x SC, multimode
5*
XB205-3LD (SC) 5x RJ45 3x SC, single-mode 26**
XB205-3
5x RJ45
3x ST, multimode
5*
XB216 16x RJ45 - -
XB213-3 (SC)
13x RJ45
3x SC, multimode
5*
XB213-3LD (SC)
13x RJ45
3x SC, single-mode
26**
XB213-3
13x RJ45
3x ST, multimode
5*
* With a cable cross-section of 50/125 μm or 62.5/125 μm; attenuation 1 dB/km at 1310 nm;
1200 MHz * km
** With a cable cross-section of 9/125 μm; attenuation ≤ 0.5 dB/km at 1310 nm
4.5.13.4 Article numbers
Device
Description
Article number
(Ethernet/IP)
Article number
(PROFINET)
SCALANCE XB208
8 x 10/100 Mbps RJ-45 ports
6GK5208-0BA00-2TB2
6GK5208-0BA00-2AB2
SCALANCE XB205-3 (SC) 5 x 10/100 Mbps RJ-45 ports, 3 x
10/100 Mbps SC ports, multimode
fiber-optic cable
6GK5205-3BD00-2TB2 6GK5205-3BD00-2AB2
SCALANCE XB205-3LD
(SC)
5 x 10/100 Mbps RJ-45 ports, 3 x
10/100 Mbps SC ports, single mode
fiber-optic cable
6GK5205-3BF00-2TB2 6GK5205-3BF00-2AB2
SCALANCE XB205-3 5 x 10/100 Mbps RJ-45 ports, 3 x
10/100 Mbps ST ports, multimode
fiber-optic cable
6GK5205-3BB00-2TB2 6GK5205-3BB00-2AB2
SCALANCE XB216
16 x 10/100 Mbps RJ-45 ports
6GK5216-0BA00-2TB2
6GK5216-0BA00-2AB2
SCALANCE XB213-3 (SC) 13 x 10/100 Mbps RJ-45 ports, 3 x
10/100 Mbps SC ports, multimode
fiber-optic cable
6GK5213-3BD00-2TB2 6GK5213-3BD00-2AB2
SCALANCE XB213-3LD
(SC)
13 x 10/100 Mbps RJ-45 ports, 3 x
10/100 Mbps SC ports, single mode
fiber-optic cable
6GK5213-3BF00-2TB2 6GK5213-3BF00-2AB2
SCALANCE XB213-3 13 x 10/100 Mbps RJ-45 ports, 3 x
10/100 Mbps ST ports, multimode
fiber-optic cable
6GK5213-3BB00-2TB2 6GK5213-3BB00-2AB2
