Siemens SIMATIC NET System Manual

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
156 System Manual, 09/2019, C79000-G8976-C242-10
4.5.12.3 Interfaces
Device
Total number of
available ports
Twisted pair
Fiber-optic cables
Combo ports
10/100 Mbps
10/100 Mbps
100/1000 Mbps
X204RNA 4 4x RJ45
(of which 2x PRP
ports)
- - -
X204RNA EEC 4
1)
Max. 4x RJ45
(of which 2x PRP
ports)
- - 2x SFP (100 Mbps)
as PRP ports
1)
Of which 2 are combo ports
Note
TP connectors of SCALANCE X204RNA EEC
2x RJ
45 for connecting two end devices / network structures without PRP-1 capability and
optionally 2x RJ45 or 2x SFP modules for
connecting network structures capable of PRP. If
an SFP module is inserted, the corresponding RJ45 jack is deactivated.
Example: If
SFP module "PRP A" is inserted, the TP Interface "PRP A" has no function.
Note
SCALANCE X200RNA
The networks LAN A
and/or LAN B can have PROFINET or IRT functionality. These cannot,
however, be transferred via the SCALANCE X200RNA because PRP does not
support this.
PRP functionality is not impaired by using PROFINET or IRT components in the LAN A and
LAN B networks.
4.5.12.4 Article numbers
Device
Description
Supported modes
Article number
SCALANCE X204RNA (PRP) 4x 100 Mbps RJ45 ports PRP ↔ standard Ethernet
PRP ↔ HSR link
6GK5204-0BA00-2KB2
SCALANCE X204RNA (HSR) HSR ↔ Standard Ethernet;
HSR ↔ PRP coupling
6GK5204-0BA00-2MB2
SCALANCE X204RNA EEC (PRP)
2x 100 Mbps RJ45 ports and
2x 100 Mbps combo ports
PRP ↔ standard Ethernet
6GK5204-0BS00-3LA3
SCALANCE X204RNA EEC (HSR) HSR ↔ Standard Ethernet;
HSR ↔ PRP coupling
6GK5204-0BS00-2NA3
SCALANCE X204RNA EEC
(PRP/HSR)
PRP ↔ Standard Ethernet;
HSR ↔ Standard Ethernet;
HSR ↔ PRP link
6GK5204-0BS00-3PA3
