SCALANCE network components
4.6 SCALANCE W components for the Industrial Wireless LAN
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
233
4.6.12.3 Interfaces
Internal antennas 8
Connections for external antennas
Ethernet interface 10/100/1000 Mbps 2x RJ45
Connection PoE according to IEEE 802.3af / 802.3at for Type 1
Article numbers
SCALANCE W1750D-2IA RJ45 2x RJ45 Ethernet interfaces, max.
1 Gbps, PoE
2x integral wireless cards
8x
integrated omnidirectional an-
6GK5750-2HX01-1AA0
6GK5750-2HX01-1AB0
1)
6GK5750-2HX01-1AD0
2)
US variant
4.6.13 Antennas
4.6.13.1 How it works
How antennas work
The task of an antenna is to convert electrical current into electromagnetic waves and vice
versa. A basic distinction is made between detached and directly mounted or integrated
antennas. Detached antennas increase the reliability of wireless links by optimizing the
transmit and receive conditions because these antennas can be mounted at a location with
optimum wireless conditions. A cable connects the detached antenna and access point or
client. The antennas operated directly on the device allow compact, low-maintenance
installation.
Antennas can communicate in the 2.4 GHz or 5 GHz frequency band or in both frequency
bands.
