SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
163
● Configuration with STEP 7 V 5.3 plus SP 1
● Web Based Management
● Command Line Interface / Telnet
● SNMP / SNMP-supported diagnostics
● SNTP
● Ring redundancy including RM functionality
● MRP interconnection
● Standby redundancy
● STP/RSTP (Spanning Tree Protocol/Rapid Spanning Tree Protocol) and RSTP+
● Passive listening
● Topology support (LLDP)
● Link aggregation (IEEE 802.3ad)
● VLAN (Virtual Local Area Network) port based
● IGMP Snooping/Querier (Internet Group Management Protocol)
● IEEE 802.1x (radius)
● PROFINET diagnostics
● All models are available in two variants: PROFINET and EtherNet/IP The mode can,
however, be switched over as required with both device variants.
● In the EtherNet/IP mode, the devices also have EtherNet/IP diagnostics.
4.5.14.3 Interfaces
Total num-
ber of avail-
able ports
XC206-2 (ST/BFOC) 8 6x RJ45 - 2x ST/BFOC
2)
,
multimode
- -
XC206-2 (SC) 8 6x RJ45 - 2x SC
2)
, multi-
- -
XC206-2SFP 8 6x RJ45 - - 2x
-
XC206-2SFP EEC 8 6x RJ45 - - 2x
-
