Siemens SIMATIC NET System Manual

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
180 System Manual, 09/2019, C79000-G8976-C242-10
4.5.18.2 Features and functions
Features
The individual devices have the characteristics shown in the following table:
X308-2M
XR324-12M
XR324-4M EEC
X308-2M TS
XR324-12M TS
X308-2M PoE
XR324-4M PoE
Modular design
●
●
●
Gigabit Ethernet ● ● ●
PoE Power over Ethernet
-
-
●
Diagnostics LED ● ● ●
Redundant power supply
●
1)
●
●
1)
Railway applications
-
●
-
On site display (Set button)
●
●
●
C-PLUG slot
●
●
●
● Suitable / available or
according to the specified standard
1)
Only for devices variants with 24 V DC
Functions
All devices have the following functions:
● Configuration with the Primary Setup Tool (PST) V3 or higher;
to use the Primary Setup Tool to assign the IP address, the switches must be accessible
via Ethernet.
● Configuration of the IP address with DHCP
● Configuration with STEP 7
● Web Based Management
● Command Line Interface/Telnet
● SNMP / SNMP-supported diagnostics
● SNTP
● Ring redundancy including RM functionality
● Standby redundancy
● MRP interconnection
● STP/RSTP (Spanning Tree Protocol/Rapid Spanning Tree Protocol) as well as RSTP+
● Passive Listening
● Topology support (LLDP)
● VLAN (Virtual Local Area Network)
● GVRP (Generic VLAN Registration Protocol)
