Siemens SIMATIC NET System Manual

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
170 System Manual, 09/2019, C79000-G8976-C242-10
● SNMP / SNMP-supported diagnostics
● SNTP
● Ring redundancy including RM functionality
● Passive Listening
● Topology support (LLDP)
● PROFINET diagnostics
The IRT devices have the following additional functions:
● Standby redundancy
● IRT capability
4.5.15.3 Interfaces
Device
Twisted pair
Fiber-optic cables
10/100 Mbps
10/100 Mbps
Max. segment length / km
XF204
4x RJ45
-
-
XF204-2 4x RJ45 2x ST/BFOC, multimode 4* / 5**
XF206-1 6x RJ45 1x ST/BFOC, multimode 4* / 5**
XF208
8x RJ45
-
-
XF201-3P IRT
1x RJ45
3x SC RJ/ push-pull plug, POF
-
XF202-2P IRT
2x RJ45
2x SC RJ/push-pull plug, POF
-
XF204IRT
4x RJ45
-
-
XF204-2BA IRT
Basic device without
BusAdapter
0x RJ45 - -
* With a cable cross-section of 50 µm
** With a cable-cross section of 62.5 µm
4.5.15.4 Article numbers
Device
Description
Article number
SCALANCE XF204
4 x 10/100 Mbps RJ-45 ports electrical
6GK5204-0BA00-2AF2
SCALANCE XF204-2 4x 10/100 Mbps RJ45 ports electrical, 2x
100 Mbps BFOC ports optical (multimode,
glass), up to max. 5 km
6GK5204-2BC00-2AF2
SCALANCE XF206-1 6 x 10/100 Mbps RJ-45 ports electrical, 1x
100 Mbps BFOC port optical (multimode,
glass), up to max. 5 km
6GK5206-1BC00-2AF2
SCALANCE XF208
8x 10/100 Mbps RJ45 ports electrical
6GK5208-0BA00-2AF2
