Siemens SIMATIC NET System Manual

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
149
XC106-2
XC108
XC116
XC124
Signaling contact
●
On site display (Set button)
●
● Suitable / available or according to the specified standard
4.5.9.3 Interfaces
Device
Twisted pair
Fiber-optic cables
10/100 Mbps
10/100 Mbps
Max. segment length /
km
XC106-2 (SC)
6x RI45
2x SC, multimode
5*
XC106-2 (ST)
6x RI45
2x ST/BFOC, multimode
5*
XC108
8x RI45
-
-
XC116
16x RI45
-
-
XC124
24x RI45
-
-
* With a cable cross-section of 50/125 μm or 62.5/125 μm; attenuation ≤ 1 dB/km at
1310 nm; 1200 MHz * km
4.5.9.4 Article numbers
Device
Description
Article number
SCALANCE XC106-2 (SC) 6x 10/100 Mbps RJ45 ports, 2x
10/100 Mbps SC ports, multimode fiber-
optic cable
6GK5 106-2BD00-2AC2
SCALANCE XC106-2
(ST/BFOC)
6x 10/100 Mbps RJ45 ports, 2x
10/100 Mbps ST/BFOC ports, multimode
fiber-optic cable
6GK5 106-2BB00-2AC2
SCALANCE XC108
8x 10/100 Mbps RJ45 ports
6GK5 108-0BA00-2AC2
SCALANCE XC116
16x 10/100 Mbps RJ45 ports
6GK5 116-0BA00-2AC2
SCALANCE XC124
24x 10/100 Mbps RJ45 ports
6GK5 124-0BA00-2AC2
