SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
191
Multicast routing (PIM-SM, PIM-SSM, PIM-BiDir, MSDP)
IPv6:
Management
RIPng
OPSFv3
VRRPv3
4.5.20.3 Interfaces
Device
Total number of availa-
ble ports
Twisted pair
Fiber-optic cables
Combo ports
100/1000 Mbps
10/100/1000 Mbps
1000 Mbps
XM408-4C
8
1)
Max. 8x RJ45
-
4x STP/SCP
XM408-8C
8
2)
Max. 8x RJ45
-
8x SFP
XM416-4C 16
1)
Max. 16x RJ45 - 4x SFP
1)
Of which 4 are combo ports
2)
Of which 8 are combo ports
4.5.20.4 Article numbers
Device
Description
Article number
SCALANCE XM408-4C 4x 10/100/1000 Mbps RJ45 ports,
4x combo ports (usable either for plug-in
transceiver STP/SCP 100/1000 Mbps or as
10/100/1000 Mbps RJ45 ports);
Up to 2 port extenders, Layer 3 integrated
via KEY-PLUG
6GK5408-4GP00-2AM2
4x 10/100/1000 Mbps RJ45 ports,
4x combo ports (usable either for plug-in
transceiver STP/SCP 100/1000 Mbps or as
10/100/1000 Mbps RJ45 ports);
Up to 2 port extenders, Layer 3 integrated
6GK5408-4GQ00-2AM2
SCALANCE XM408-8C 8x combo ports (usable either for plug-in
transceiver SFP 100/1000 Mbps or as
10/100/1000 Mbps RJ45 ports);
Up to 2 port extenders, Layer 3 via KEY-
PLUG
6GK5408-8GS00-2AM2
8x combo ports (usable either for plug-in
transceiver SFP 100/1000 Mbps or as
10/100/1000 Mbps RJ45 ports);
up to 2 port extenders, Layer 3 integrated
6GK5408-8GR00-2AM2
