Siemens SIMATIC NET System Manual

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
199
● GMRP (Generic Multicast Protocol)
● Broadcast, Multicast, Unicast limiter
● Broadcast blocking
● DHCP server / DHCP client / DHCP options 66, 67, 82
● Access Control List (ACL)
● IEEE 802.1x (Radius)
● Link aggregation
● Static IP routing
● RIPv2 (dynamic routing)
● OSPFv2 (dynamic routing)
● VRRP, router redundancy (Virtual Router Redundancy Protocol)
● PROFINET diagnostics
● Multicast routing (PIM-SM, PIM-SSM, PIM-BiDir, MSDP)
● IPv6:
– Management
– RIPng
– OPSFv3
– VRRPv3
4.5.21.3 Interfaces
Device
Total num-
ber of avail-
able ports
Twisted pair
Fiber-optic
cables
Combo ports
SFP slots
Slots for 4-port media
modules
10/100/1000 Mbps
1000 Mbps
100/1000 Mbps
1/10 Gbps
100/1000 Mbps
XR524-8C
24
1)
Max. 24x RJ45
-
8x SFP
-
-
XR526-8C
26
1)
Max. 24x RJ45
-
8x SFP
2x SFP+
-
XR528-6M 28 - - - 4x SFP+ 6
XR552-12M
52
-
-
4x SFP+
12
1)
of which 8 are combo ports
4.5.21.4 Article numbers
Device
Properties
Layer 3
Power supply
Article number
SCALANCE XR524-8C 1 height unit;
16x 10/100/1000 Mbps RJ45
ports,
KEY-PLUG 2 x 24 VDC
Connectors on front
6GK5524-8GS00-2AR2
1 x 100 to 240 VAC
Connector on rear
6GK5524-8GS00-3AR2
