Siemens SIMATIC NET System Manual

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
200 System Manual, 09/2019, C79000-G8976-C242-10
Device
Properties
Layer 3
Power supply
Article number
8x combo ports (usable
either for plug-in transceiver
SFP 100/1000 Mbps or as
10/100/1000 Mbps RJ45
ports)
2 x 100 to 240 VAC
Connectors on rear
6GK5524-8GS00-4AR2
Integrated 2 x 24 VDC
Connectors on front
6GK5524-8GR00-2AR2
1 x 100 to 240 VAC
Connector on rear
6GK5524-8GR00-3AR2
2 x 100 to 240 VAC
Connectors on rear
6GK5524-8GR00-4AR2
SCALANCE XR526-8C 1 height unit;
16x 10/100/1000 Mbps RJ45
ports,
8x combo ports (usable
either for plug-in transceiver
SFP 100/1000 Mbps or as
10/100/1000 Mbps RJ45
ports)
2x 10 Gbps SFP+ transceiv-
er
KEY-PLUG
2 x 24 VDC
Connectors on front
6GK5526-8GS00-2AR2
1 x 100 to 240 VAC
Connector on rear
6GK5526-8GS00-3AR2
2 x 100 to 240 VAC
Connectors on rear
6GK5526-8GS00-4AR2
Integrated 2 x 24 VDC
Connectors on front
6GK5526-8GR00-2AR2
1 x 100 to 240 VAC
Connector on rear
6GK5526-8GR00-3AR2
2 x 100 to 240 VAC
Connectors on rear
6GK5526-8GR00-4AR2
Device
Properties
Layer 3
Cable outlet
Article number
SCALANCE XR528-6M 2 height units;
4x 1/10 Gbps SFP+slots,
6x 100/1000 Mbps slots for
4-port media modules (de-
pending on the plugged
media module: electrical,
electrical PoE or optical)
KEY-PLUG
Front
6GK5528-0AA00-2AR2
Back
6GK5528-0AA00-2HR2
Integrated Front 6GK5528-0AR00-2AR2
Back 6GK5528-0AR00-2HR2
SCALANCE XR552-12M 3 height units;
4x 1/10 Gbps SFP+slots,
12x 100/1000 Mbps slots for
4 port media modules (de-
pending on the plugged
media module: electrical,
electrical PoE or optical)
KEY-PLUG
Front
6GK5552-0AA00-2AR2
Back
6GK5552-0AA00-2HR2
Integrated
Front
6GK5552-0AR00-2AR2
Back 6GK5552-0AR00-2HR2
