SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
186 System Manual, 09/2019, C79000-G8976-C242-10
Functions
All devices have the following functions:
● Configuration with the Primary Setup Tool (PST) V3 or higher;
to assign the IP address using the Primary Setup Tool, the switch must be accessible via
Ethernet.
● Configuration of the IP address with DHCP
● Configuration with STEP 7
● Web Based Management
● Command Line Interface/Telnet
● SNMP / SNMP-supported diagnostics
● SNTP
● Ring redundancy including RM functionality
● Standby redundancy
● Passive Listening
● Topology support (LLDP)
● VLAN (Virtual Local Area Network)
● STP/RSTP (Spanning Tree Protocol/Rapid Spanning Tree Protocol)
● IGMP snooping/querier (Internet Group Management Protocol)
● DHCP server / DHCP client / DHCP options 66, 67, 82
● Unicast Filter
● Broadcast blocking / multicast blocking / unicast blocking
● Management ACL
● IEEE 802.1x (Radius)
● PROFINET diagnostics
4.5.19.3 Interfaces
Total number of
available ports
1)
1)
Of which 4 are combo ports
