Siemens SIMATIC NET System Manual

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
176 System Manual, 09/2019, C79000-G8976-C242-10
The devices support the S2 system redundancy and H-Sync and can be integrated into
SIMATIC S7-1500 R/H systems. In addition, the devices support Configuration in Run
(CiR/H-CiR). This enables configuration changes defined via PROFINET to be performed at
the switch during operation.
The configuration data can also be stored on the optionally available C-PLUG removable
data storage medium. This enables quick configuration of a new device during device
replacement.
All devices are suitable for the industry protocol PROFINET. The two models XP-208 and
XP-216 are also available preassembled ex factory for EtherNet/IP.
4.5.17.2 Features and functions
Features
The individual devices have the characteristics shown in the following table:
XP208
XP208 EEC
XP208PoE EEC
XP216
XP216 EEC
XP216PoE EEC
Gigabit Ethernet
-
-
-
●
●
●
PoE Power over Ethernet - - ● - - ●
Diagnostics LED
●
●
●
●
●
●
Redundant power supply ● ● ● ● ● ●
Signaling contact
●
●
●
●
●
●
Railway approval
-
●
●
-
●
●
On site display (Set button)
●
●
●
●
●
●
C-PLUG slot
●
●
●
●
●
●
● Suitable / available or according to the specified standard
Functions
All devices have the following functions:
● Configuration with the Primary Setup Tool (PST) V3 or higher;
to use the Primary Setup Tool to assign the IP address, the switches must be accessible
via Ethernet.
● Configuration of the IP address with DHCP
● Configuration with STEP 7
● Web Based Management
● Command Line Interface / Telnet
● SNMP / SNMP-supported diagnostics
● SNTP
● Ring redundancy including RM functionality
● Standby redundancy
