Siemens SIMATIC NET System Manual

SCALANCE network components
4.7 SCALANCE M industry router
Industrial Ethernet
246 System Manual, 09/2019, C79000-G8976-C242-10
M812-1
M816-1
M826-2
DSL interface 1x RJ45 1x RJ45 Terminal strip for 2-
wire/4-wire cable
Digital input/output 1/1 1/1 1/1
Power supply 24 V DC
●
●
●
Redundant power supply
●
●
●
C-PLUG slot
-
●
●
● Suitable / available or according to the specified standard
Functions
● Industrial Ethernet interface 10/100 Mbps, TP, autocrossover
● Configuration using the WBM, CLI or SNMP
● MIB support
● HTTP, HTTPS
● SNMPv1, SNMPv2, SNMPv2c and SNMPv3
● DHCP client
● DHCP server for internal network
● NAT (IP masquerading, NAT traversal, 1:1 NAT)
● Port forwarding
● DNS cache
● Firewall (stateful packet inspection)
● VPN with up to 20 connections
● IPsec
● NTP
● SNTP
4.7.2.3 Article numbers
Device
Description
Article number
SCALANCE M812-1 ADSL router with connector for the internal net-
work
ADSL2+ (Annex A)
6GK5812-1AA00-2AA2
ADSL2+ (Annex B)
6GK5812-1BA00-2AA2
SCALANCE M816-1
ADSL router 4-port switch
ADSL2+ (Annex A)
6GK5816-1AA00-2AA2
ADSL2+ (Annex B)
6GK5816-1BA00-2AA2
SCALANCE M826-2
SHDSL router with 4-port switch.
6GK5826-2AB00-2AB2
