Siemens SIMATIC NET - Media Modules and SFP Transceivers

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
183
Device
Description
Article number
SCALANCE XR324-4M PoE Partially modular 19" Industrial Ethernet
switch;
8x 10/100/1000 Mbps RJ45 Ports with PoE
8x 10/100/1000 Mbps RJ45 ports without
PoE
4x 10/100/1000 Mbps slots for 2-port media
modules, optionally electrically or optically
equipped
24 VDC power supply
Data cable outlet front
6GK5324-4QG10-1AR2
Data cable outlet back
6GK5324-4QG10-1HR2
110 to 230 VAC power supply
Data cable outlet front
6GK5324-4QG10-3AR2
Data cable outlet back
6GK5324-4QG10-3HR2
SCALANCE XR324-4M PoE
TS
Partially modular 19" Industrial Ethernet
switch;
8x 10/100/1000 Mbps RJ45-Ports with PoE
8x 10/100/1000 Mbps RJ45 ports without
PoE
4x 10/100/1000 Mbps slots for 2-port media
modules, optionally electrically or optically
equipped
Power supply 24 V DC, data cable outlet
front
with extended temperature range and EN
50155/ EN 50121-4 approval for railway
applications.
6GK5324-4QG10-1CR2
4.5.18.5 Media modules and SFP transceivers
Media modules
The use of media modules in partially and fully modular variants of the SCALANCE X-300
switches allows the expansion of networks by subsequently plugging additional media
modules into unused media module slots and allows a change of the cabling technology (for
example a change from copper to fiber-optic or from multimode to single mode fiber-optic
cable).
Component
Twisted pair
Fiber-optic cables
10/100 Mbps
10/100/1000
Mbps
100 Mbps
1000 Mbps
Max. segment length /
km
MM991-2
-
-
2x ST, multimode
-
4* / 5**
MM991-2LD
-
-
2x ST, single-mode
-
26
MM991-2
-
-
2x SC, multimode
-
4* / 5**
MM991-2LD
-
-
2x SC, single-mode
-
26
MM991-2LH+
-
-
2x SC, single-mode
-
70
MM992-2CUC
-
2x RJ45
-
-
-
