Siemens SIMATIC NET - Page 182

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
182 System Manual, 09/2019, C79000-G8976-C242-10
Device
Description
Article number
SCALANCE X308-2M TS 4x 10/100//1000 Mbps RJ45 ports, electri-
cal
2x 10/100/1000 Mbps slots for 2 port media
modules, electrical or optical, with extend-
ed temperature range and approval EN
50155/EN 50121-4 for railway applications
6GK5308-2GG10-2CA2
SCALANCE XR324-12M Fully modular 19" Industrial Ethernet
switch;
12x 10/100/1000 Mbps slots for 2-port
media modules, optionally electrically or
optically equipped
24 VDC power supply
Data cable outlet front
6GK5324-0GG10-1AR2
Data cable outlet rear
6GK5324-0GG10-1HR2
Power supply 110 to 230 V AC
Data cable outlet front
6GK5324-0GG10-3AR2
Data cable outlet rear
6GK5324-0GG10-3HR2
SCALANCE XR324-12M TS Fully modular 19" Industrial Ethernet
switch;
12x 10/100/1000 Mbps slots for 2-port
media modules, optionally electrically or
optically equipped
Power supply 24 V DC, data cable outlet
front
with extended temperature range and EN
50155/ EN 50121-4 approval for railway
applications
6GK5324-0GG10-1CR2
SCALANCE XR324-4M EEC Partially modular 19" Industrial Ethernet
switch; 8x 10/100/1000 Mbps RJ45 ports
with PoE; 8x 10/100/1000 Mbps RJ45 ports
without PoE; 4x 10/100/1000 Mbps slots for
2-port media modules, optionally electrical-
ly or optically equipped,
with extended temperature range
Power supply 1x 24 V DC
Data cable outlet front
6GK5324-4GG10-1ER2
Data cable outlet rear
6GK5324-4GG10-1JR2
Power supply 2x 24 V DC
Data cable outlet front
6GK5324-4GG10-2ER2
Data cable outlet back
6GK5324-4GG10-2JR2
110 to 230 VAC power supply
Data cable outlet front
6GK5324-4GG10-3ER2
Data cable outlet rear
6GK5324-4GG10-3JR2
Voltage supply 2x 110 to 230 V AC
Data cable outlet front
6GK5324-4GG10-4ER2
Data cable outlet back
6GK5324-4GG10-4JR2
