Siemens SIMATIC NET System Manual

SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
181
● IGMP snooping/querier (Internet Group Management Protocol)
● DHCP server / DHCP client / DHCP options 66, 67, 82
● GMRP (Generic Multicast Protocol)
● Broadcast, Multicast, Unicast limiter
● Broadcast blocking
● Access Control List (ACL), MAC and IP-based
● IEEE 802.1x (Radius)
● Link aggregation
● PROFINET diagnostics
4.5.18.3 Interfaces
Device
Total num-
ber of avail-
able ports
Twisted pair
Fiber-optic ca-
bles
Slots for 2 port media
modules
10/100/1000 Mbps
10/100 Mbps
10/100/1000 Mbps
100/1000 Mbps
X308-2M
8
-
4x RJ45
-
2
X308-2M PoE
8
-
4x RJ45
1)
2
X308-2M TS 8 - 4x RJ45 - 2
XR324-12M
24
-
-
-
12
XR324-12M TS
24
-
-
-
12
XR324-4M EEC 24 - 16x RJ45 (of which 8
1)
)
- 4
XR324-4M PoE 24 - 16x RJ45 (of which 8
1)
)
- 4
XR324-4M PoE TS 24 - 16x RJ45 (of which 8
1)
)
- 4
1)
PoE connections
4.5.18.4 Article numbers
Device
Description
Article number
SCALANCE X308-2M 4x 10/100//1000 Mbps RJ45 ports, electri-
cal
2x 10/100/1000 Mbps slots for 2-port media
modules, electrical or optical
6GK5308-2GG10-2AA2
SCALANCE X308-2M PoE 4x 10/100/1000 Mbps RJ45 ports with PoE,
electrical
2x 10/100/1000 Mbps slots for 2-port media
modules, electrical or optical
6GK5308-2QG10-2AA2
