Page #164 background image
SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
164 System Manual, 09/2019, C79000-G8976-C242-10
Device
Total num-
ber of avail-
able ports
Twisted pair
Fiber-optic ca-
bles
SFP slots
Combo ports
10/100 Mbps
10/100/1000
Mbps
100 Mbps
XC216
16
16x RJ45
-
-
-
-
XC216 EEC
16
16x RJ45
-
-
-
-
XC216-4C 16
1)
12x RJ45 Max. 4x RJ45 - - 4x SFP992
XC216-4C G 16
1)
- Max. 16x
RJ45
- - 4x SFP992
XC216-4C G EEC 16
1)
- Max. 16x
RJ45
- - 4x SFP992
XC224
24
24x RJ45
-
-
-
-
XC224-4C G 24
1)
- Max. 24x
RJ45
- - 4x SFP992
XC224-4C G EEC 24
1)
- Max. 24x
RJ45
- - 4x SFP992
1)
Of which 4 are combo ports
2)
Max. segment length 5 km with a cable cross-section of 50 or 62.5 µm; attenuation
≤ 1 dB/km at 1310 nm
4.5.14.4 Article numbers
Device
Description
Article number
(EtherNet/IP)
Article number
(PROFINET)
SCALANCE XC206-2 (ST/BFOC) 6x 10/100 Mbps RJ45 ports, 2x
100 Mbps ST/BFOC ports, mul-
timode FO cable
- 6GK5206-2BB00-2AC2
SCALANCE XC206-2 (SC) 6x 10/100 Mbps RJ45 ports, 2x
100 Mbps SC ports, multimode
FO cable
- 6GK5206-2BD00-2AC2
SCALANCE XC206-2SFP 6x 10/100 Mbps RJ45 ports, 2x
pluggable transceivers with
100/1000 Mbps
- 6GK5206-2BS00-2AC2
SCALANCE XC206-2SFP G 6x 10/100/1000 Mbps RJ45
ports, 2x pluggable transceiver
slots with 1000 Mbps
6GK5206-2GS00-2TC2 6GK5206-2GS00-2AC2
SCALANCE XC206-2SFP EEC 6x 10/100 Mbps RJ45 ports, 2x
pluggable transceivers with
100/1000 Mbps, coated PCB
- 6GK5206-2BS00-2FC2
SCALANCE XC206-2SFP G EEC 6x 10/100/1000 Mbps RJ45
ports, 2x pluggable transceiver
slots with 1000 Mbps, coated
PCB
- 6GK5206-2GS00-2FC2
SCALANCE XC208
8x 10/100 Mbps RJ45 ports
-
6GK5208-0BA00-2AC2
SCALANCE XC208G
8x 10/100/1000 Mbps RJ45 ports
6GK5208-0GA00-2TC2
6GK5208-0GA00-2AC2
