Siemens SIMATIC NET System Manual

SCALANCE network components
4.6 SCALANCE W components for the Industrial Wireless LAN
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
223
● iREF (only in access point mode)
● AeroScout (only in access point mode)
For more detailed information on this, please refer to the documentation of the AeroScout
company (www.aeroscout.com).
4.6.9.3 Interfaces
W786-1 RJ45
W786-2 RJ45
W786-2 SFP
W786-2IA RJ45
Number of wireless interfaces
1
2
2
2
Connectors for external antennas 3 6 6 -
Internal antennas
-
-
-
6
Type and number of Ethernet inter-
faces
1x RJ45 1x RJ45 2x SFP 1x RJ45
4.6.9.4 Article numbers
Access points
Device
Description
Article number
SCALANCE W786-1 RJ45 Ethernet interface RJ45,
3x external antennas
6GK5786-1FC00-0AA0
6GK5786-1FC00-0AB0
1)
SCALANCE W786-2 RJ45 Ethernet interface RJ45,
6x external antennas
6GK5786-2FC00-0AA0
6GK5786-2FC00-0AB0
1)
6GK5786-2FC00-0AC0
2)
SCALANCE W786-2IA RJ45 Ethernet interface RJ45,
6x internal antennas
6GK5786-2HC00-0AA0
6GK5786-2HC00-0AB0
1)
SCALANCE W786-2 SFP SFP slot,
6x external antennas
6GK5786-2FE00-0AA0
6GK5786-2FE00-0AB0
1)
1)
US variant
2)
Israel variant
