Siemens SIMATIC NET System Manual

SCALANCE network components
4.7 SCALANCE M industry router
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
251
Figure 4-47 Example of a topology for the remote maintenance of PROFIBUS systems via the SCALANCE M804PB
4.7.4.2 Features and functions
Features
The device has the characteristics shown in the following table:
M804PB
Diagnostics LED
●
Power supply
24 VDC
Redundant power supply
●
On site display (Set button)
●
C-PLUG slot
●
● Suitable / available or according to the specified standard
Functions
● Configuration with STEP 7
● Configuration using the WBM, CLI or SNMP
● MIB support
● TRAPs via e-mail
● HTTP, HTTPS, Telnet
● SNMPv1, SNMPv2, SNMPv2c and SNMPv3

Siemens SIMATIC NET Specifications

General

Category	Industrial Communication Software
Manufacturer	Siemens
Operating Systems	Windows, Linux
Protocols Supported	PROFIBUS, PROFINET, OPC UA
Compatibility	Siemens PLCs, Third-party devices with supported protocols
