SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
171
SCALANCE XF201-3P IRT 1x 10/100 Mbps RJ45 ports, 3 x 100 Mbps
POF SC RJ ports, BusAdapter installed
6GK5201-3BH00-2BD2
SCALANCE XF202-2P IRT 2x 10/100 Mbps RJ45 ports, 2x 100 Mbps
POF SC RJ ports, BusAdapter installed
6GK5202-2BH00-2BD2
4 x 10/100 Mbps RJ-45 ports
4x 10/100 Mbps, 2x BusAdapter interface
4.5.15.5 Accessories bus adapter
The bus adapters allow you a free choice of the connector technology for SCALANCE XF-
200 IRT.
The SCALANCE XF-200 IRTs support the following bus adapters:
BA 2×RJ45 *
)
PROFINET bus adapter with Ethernet
socket for standard RJ-45 plugs
6ES7193-6AR00-0AA0
BA 2×FC *
)
PROFINET bus adapter with FastConnect
Ethernet connector for direct connection of
6ES7193-6AF00-0AA0
BA 2xSCRJ PROFINET bus adapter with fiber-optic
6ES7193-6AP00-0AA0
BA SCRJ/RJ45 Media converter, PROFINET BusAdapter
with fiber-optic connector POF/PCF ↔
6ES7193-6AP20-0AA0
BA SCRJ/FC Media converter, PROFINET BusAdapter
with fiber-optic connector POF/PCFv↔
direct connection of the bus cable
6ES7193-6AP40-0AA0
BA 2xLC SIMATIC BusAdapter with two LC sockets
6ES7193-6AG00-0AA0
BA LC/RJ45 SIMATIC BusAdapter with one LC socket
and one RJ45 socket each (media convert-
6ES7193-6AG20-0AA0
BA LC/FC SIMATIC BusAdapter with an LC socket
and a FastConnect connection (media
6ES7193-6AG40-0AA0
*
)
The approvals for shipbuilding are only valid with the indicated bus adapters
