SCALANCE network components
4.6 SCALANCE W components for the Industrial Wireless LAN
Industrial Ethernet
230 System Manual, 09/2019, C79000-G8976-C242-10
W1788-1 M12
W1788-2 M12
W1788-2 M12 EEC
W1788-2IA M12
W1748-1 M12
Connectors for external
antennas
4x N-Connect female 8x N-Connect female - 4x N-Connect female
Connector for
10/100/1000 Mbps Ethernet
with PoE according to
IEEE 802.3at
2x M12 (X-coded) 2x M12 (X-coded) 2x M12 (X-coded) 2x M12 (X-coded)
4.6.11.4 Article numbers
Access points
Device
Description
Article number
SCALANCE W1788-1 M12 2x M12 Ethernet interfaces, max.
1 Gbps, PoE
1x integral wireless card
4x N-Connect female antenna con-
nections
6GK5788-1GY01-0AA0
6GK5788-1GY01-0AB0
1)
SCALANCE W1788-2 M12 2x M12 Ethernet interfaces, max.
1 Gbps, PoE
2x integral wireless cards
8x N-Connect female antenna con-
nections
6GK5788-2GY01-0AA0
6GK5788-2GY01-0AB0
1)
SCALANCE W1788-2 M12 EEC 2x M12 Ethernet interfaces, max.
1 Gbps, PoE
2x integral wireless cards
8x N-Connect female antenna con-
nections
6GK5788-2GY01-0TA0
6GK5788-2GY01-0TB0
1)
SCALANCE W1788-2IA M12 2x M12 Ethernet interfaces, max.
1 Gbps, PoE
2x integral wireless cards
8x internal antennas
6GK5788-2HY01-0AA0
6GK5788-2HY01-0AB0
1)
1)
US variant
Clients
Device
Description
Article number
SCALANCE W1748-1 M12 2x M12 Ethernet interfaces, max.
1 Gbps, PoE
1x integral wireless card
4x N-Connect female antenna con-
nections
6GK5748-1GY01-0AA0
6GK5748-1GY01-0AB0
1)
1)
US variant
