Siemens SIMATIC NET System Manual

SCALANCE network components
4.6 SCALANCE W components for the Industrial Wireless LAN
Industrial Ethernet
226 System Manual, 09/2019, C79000-G8976-C242-10
● STP / RSTP (IEEE 802.1d/w)
● WDS (Wireless Distribution System)
● Operation possible as IWLAN client
● VLANs (Multi-SSID)
With the optionally available KEY-PLUG, the following functions can be used:
● iPCF
● iPCF-MC
● iPRP
● iREF (only in access point mode)
● AeroScout (only in access point mode)
For more detailed information on this, please refer to the documentation of the AeroScout
company (www.aeroscout.com).
4.6.10.3 Interfaces
W788-1 RJ45
W748-1 RJ45
W788-2 RJ45
W788-1 M12
W748-1 M12
W788-2 M12
W788-2 M12 EEC
WLAN interface
1x RJ45
2x RJ45
1x M12
2x M12
Internal antennas - - - -
Connectors for external antennas
3x R-SMA female
6x R-SMA female
3x N-Connect female
6x N-Connect female
Connector for 10/100/1000 Mbps
Ethernet with PoE according to
IEEE 802.3at
1x RJ45 1x RJ45 1x M12 (X-coded) 1x M12 (X-coded)
4.6.10.4 Article numbers
Access points
Device
Description
Article number
SCALANCE W788-1 RJ45 Ethernet interface 1x RJ45 max. 1
Gbps, PoE
1x integral wireless card
3x R-SMA antenna connections
6GK5788-1FC00-0AA0
6GK5788-1FC00-0AB0
1)
SCALANCE W788-2 RJ45 Ethernet interface RJ45 max. 1
Gbps, PoE
2x integral wireless cards
6x R-SMA antenna connections
6GK5788-2FC00-0AA0
6GK5788-2FC00-0AB0
1)
6GK5788-2FC00-0AC0
2)
SCALANCE W788-1 M12 Ethernet interface 1x M12 max. 1
Gbps, PoE
1x integral wireless card
3x N-Connect female
6GK5788-1GD00-0AA0
6GK5788-1GD00-0AB0
1)
