SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
195
SCALANCE XM-400 basic devices are not capable of PoE. With the extnder module
PE408PoE, however, the XM-400 devices can be expanded with ports that allow a power
supply via Ethernet.
Interfaces
1)
1)
PoE connections; separate supply of PoE voltage via two PoE input ports required
Article numbers
8 x 10/100/1000 Mbps RJ-45 ports
8 x 10/100/1000 Mbps, RJ-45 ports with PoE
8 x 100/1000 Mbps, SFP ports
4.5.20.7 External power supply units SCALANCE PS-900PoE
Figure 4-27 SCALANCE PS9230 PoE and SCALANCE PS924 PoE
Description
The power supply units of the SCALANCE PS-900 PoE series, were specially developed to
supply the extender module PE408PoE with power. There are two product variants
available:
● SCALANCE PS9230 PoE for 120/230 VAC input voltage
● SCALANCE PS924 PoE for 24 VDC input voltage
