SCALANCE network components
4.5 SCALANCE X Industrial Ethernet Switches
Industrial Ethernet
196 System Manual, 09/2019, C79000-G8976-C242-10
The devices with degree of protection IP20 can be used in ambient temperatures between -
40 °C und +70 °C. A SCALANCE PS-900 PoE supplies a maximum power of 86 W. To
supply all eight ports of a PE408PoE with power two SCALANCE PS-900 PoE must
therefore be connected.
Features
SCALANCE PS9230 PoE
SCALANCE PS924 PoE
Input voltage
85 ... 264 VAC at 47 ... 63 Hz
19.2 ... 28.8 VDC
Output voltage
48 ... 54 VDC, can be set
Output effective power
86 W
Effective power loss 14 W
Diagnostics LED
Signaling contact
Interfaces
Electrical connectors
SCALANCE PS9230 PoE
SCALANCE PS924 PoE
Power supply At the input FE / + / - screw terminals 0.5
- 2.5 mm²
IEC plug
At the input 2x + / 2x -, screw terminals
0.5 - 2.5 mm²
2x + / 2x -, screw terminals
0.5 - 2.5 mm²
Signaling contact 2 screw terminals 0.5-2.5 mm²
Article numbers
Device
Description
Article number
SCALANCE PS9230 PoE PoE power supply for SCALANCE
PE408PoE with 230 V AC input voltage
6GK5923-0PS00-3AA2
SCALANCE PS924 PoE PoE power supply for SCALANCE
PE408PoE with 24 V DC input voltage
6GK5924-0PS00-1AA2
