Siemens SIMATIC NET System Manual

Communications processors for SIMATIC S7
8.3 Communications processors SINAUT ST7 for SIMATIC S7-300
Industrial Ethernet
318 System Manual, 09/2019, C79000-G8976-C242-10
Functions
The communications processors of this category support the following protocols:
Protocol / function
TIM 3V-IE
TIM 3V-IE Advanced
TIM 3V-IE DNP3
TIM 4R-IE
TIM 4R-IE DNP3
TCP/IP
●
●
●
●
●
DNP3
-
-
●
-
●
SINAUT ST1
●
●
-
●
-
SINAUT ST7 ● ● - ● -
Modbus RTU
-
-
●
-
●
● Suitable / available or according to the specified standard.
The communications processors of this category have the following functions:
● Data buffering when there is a connection abort
● Configuration with SINAUT ST7 ES
Article numbers
Device
Description
Article number
TIM 3V-IE Communication module for SIMATIC S7-300; 1x RS 232 interface for
SINAUT communication via WAN and 1x RJ45 interface for SINAUT
communication via an IP-based network
6NH7800-3BA00
TIM 3V-IE Advanced Communication module for SIMATIC S7-300; 1x RS 232 interface for
SINAUT communication via WAN and 1x RJ45 interface for SINAUT
communication via an IP-based network
6NH7800-3CA00
TIM 3V-IE DNP3 Communications module for SIMATIC S7-300; 1x RS 232 interface for
DNP3 communication via a WAN and 1x RJ45 interface for DNP3 com-
munication via an IP-based network
6NH7803-3BA00-0AA0
TIM 4R-IE Communication module for SIMATIC S7-300; 2x RS 232 interface for
SINAUT communication via WAN and 2x RJ45 interfaces for SINAUT
communication via an IP-based network
6NH7800-4BA00
TIM 4R-IE DNP3 Communication module for SIMATIC S7-300; 2x RS 232 interface for
DNP3 communication via WAN and 2x RJ45 interfaces for DNP3 com-
munication via an IP-based network
6NH7803-4BA00-0AA0
