Siemens SIMATIC NET System Manual

Gateways
10.3 PN/BACnet Link Gateway
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
357
● Configuration via STEP 7 TIA Portal as of V14 SP1 or higher
● Supported controllers: S7-1200, S7-1500, ET 200SP, OpenController
Features
SIMATIC PN/BACnet link
Connection PROFINET/Industrial Ethernet
2x RJ45
Connection BACnet/IP
1x RJ45
Transmission rate - Industrial Ethernet
Max. 100 Mbps
Power supply 24 V DC
Integrated 2-port real-time switch
●
Diagnostic LEDs ●
C-PLUG slot
●
● Suitable / available or according to the specified standard.
Functions
● PROFINET IO
● Operation as "BACnet Client" or "BACnet Server"
The functionality is specified during configuration, mixed operation of client and server
functionality possible.
● Data transmission:
– Acyclic (programmed from the automation program); via the "Data record read/write"
services
– Cyclic (can be parameterized in HSP by the user); via updating of the IO image
– At change of value via Change of Value (COV) mechanism
● Scan of the BACnet/IP network
● Supported BACnet object types:
– Device
– Binary input / binary output
– Analog input / analog output
Supported BACnet services:
– DS-COV-A/B
– DM-DDB-A/B
– DM-DOB-B
– DS-RP-A/BDS-WP-A/P
– GW-EO-B
