Gateways
10.4 PN/CAN link
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
359
SIMATIC PN/CAN Link
Integrated 2-port real-time switch
Diagnostic LEDs
C-PLUG slot
Suitable / available or according to the specified standard.
Functions
PROFINET IO
Per 512 receive /transmit PDOs
Baud rates from 50 kBaud up to 1000 kBaud on the CAN side
Operating modes:
CANtransparent
CANopen Manager
CANopen slave
Data transmission:
For value change / acyclic
Acyclic communication via the "Data record read/write" services
Cyclic
Cyclic data exchange between the PN/CAN LINK and the connected SIMATIC S7
CPUs via updating of the IO image
On request from the application (RTR)
Supported CAN services:
Nodeguarding/Lifeguarding
Heartbeat
SYNC (producer / consumer)
Article numbers
Device
Description
Article number
SIMATIC PN/CAN
Link
SIMATIC PN/CAN LINK gateway from PROFINET to
CAN or CANopen networks CAN 2.0A/B CANopen
Manager to CiA301/302 CANopen slave to
CiA301/302, IP20
6BK1620-0AA00-0AA0
