Siemens SIMATIC S7-200 - Move Byte Immediate Read; Move Byte Immediate Write

SIMATIC Instructions
9-106
S7-200 Programmable Controller System Manual
A5E00066097-02
Move Byte Immediate Read
The Move Byte Immediate Read instruction reads
physical input IN and writes the result in OUT.
Error conditions that set ENO = 0: SM4.3 (run-time),
0006 (indirect address)
Inputs/Outputs Operands Data Types
IN IB BYTE
OUT VB, IB, QB, MB, SB, SMB, LB, AC, *VD, *LD, *AC BYTE
Move Byte Immediate Write
The Move Byte Immediate Write instruction reads from
location IN and writes to physical output OUT.
Error conditions that set ENO = 0: SM4.3 (run-time),
0006 (indirect address)
Inputs/Outputs Operands Data Types
IN VB, IB, QB, MB, SB, SMB, LB, AC, Constant,*VD, *LD, *AC BYTE
OUT QB BYTE
L
A
D
S
T
L
BIR IN, OUT
MOV_BIR
EN
IN OUT
F
B
D
ENO
222 224
✓✓✓
221 226
✓
L
A
D
S
T
L
BIW IN, OUT
MOV_BIW
EN
IN
OUT
F
B
D
ENO
222 224
✓✓✓
221 226
✓
