S7-200 Specifications
A-36
S7-200 Programmable Controller System Manual
A5E00066097-02
A.10 Specifications for the EM 223 Digital Combination Modules,
16 Inputs/16 Outputs
Table A-10 Specifications for EM 223 24 VDC 16 In/16 Out and EM 223 24 VDC 16 In/16 Relay Out
Description
Order Number
EM 223 DI16/DO16 X DC24V
6ES7 223-1BL20-0XA0
EM 223 DI16/DO16 X DC24V/Rly
6ES7 223-1PL20-0XA0
Physical Size
Dimensions (W x H x D)
Weight
Power loss (dissipation)
137.3 mm x 80 mm x 62 mm
360 g
6 W
137.3 mm x 80 mm x 62 mm
400 g
6 W
Input Features
Number of inputs
Input type
16 inputs
Sink/Source (IEC Type 1 sink)
16 inputs
Sink/Source (IEC Type 1 sink)
Input Voltage
Maximum continuous permissible
Surge
Rated value
Logic 1 signal (minimum)
Logic 0 signal (maximum)
30 VDC
35 VDC for 0.5 s
24 VDC at 4 mA, nominal
15 VDC at 2.5 mA, minimum
5 VDC at 1 mA, maximum
30 VDC
35 VDC for 0.5 s
24 VDC at 4 mA, nominal
15 VDC at 2.5 mA, minimum
5 VDC at 1 mA, maximum
Isolation
Optical isolation (galvanic)
Isolation groups of
500 VAC for 1 minute
8 points
500 VAC for 1 minute
8 points
Input Delay Times
Maximum
4.5 ms 4.5 ms
Connection of 2-Wire Proximity Sensor (Bero)
Maximum
1 mA 1 mA
Cable Length
Unshielded
Shielded
300 m
500 m
300 m
500 m
Number of Inputs On Simultaneously
40 ° C
55 ° C
16
16
16
16
