Siemens SIMATIC S7-200 - Set the PG;PC Interface Dialog Box

Getting Started with an S7-200 Programming System
3-7
S7-200 Programmable Controller System Manual
A5E00066097-02
Mode
Communications Links
Double click the icon representing the PLC
you
wish to communicate with.
Double click the module icon to change to
communication parameters.
Double click the modem icon to setup the
modem parameters or dial to start modem
communications.
Communications Setup
Communication Parameters
Modul
Protoc
Local
Remot
Trans
✂
Cancel
Help
OK
Interfaces
Select...
Access Path
Access Point of the Application:
Micro/WIN -->PC/PPI cable (PPI)
(Standard for Micro/WIN)
Interface Parameter Assignment Used:
PC/PPI cable (PPI)
PC internal (local)
PC/PPI cable (PPI)
Properties...
Delete
Copy...
(Assigning Parameters to a PC/PPI Cable
for a PPI Network)
PC/PPI
cable
Address: 0
Set PG/PC Interface (V5.0)
Add/Remove
CP5611(PROFIBUS)
CP5611(MPI)
CP5611(PPI)
CP5611(PROFIBUS)
Figure 3-2 Set the PG/PC Interface Dialog Box
