S7-200 Specifications
A-24
S7-200 Programmable Controller System Manual
A5E00066097-02
Table A-5 Specifications for CPU 226 DC/DC/DC and CPU 226 AC/DC/Relay (continued)
Description
Order Number
CPU 226 AC/DC/Relay
6ES7 216-2BD21-0XB0
CPU 226 DC/DC/DC
6ES7 216-2AD21-0XB0
Output Features
Number of integrated outputs
Output type
16 outputs
Solid state-MOSFET
16 outputs
Relay, dry contact
Output Voltage
Permissible range
Rated value
Logic 1 signal at maximum current
Logic 0 signal with 10 K Ω load
20.4 to 28.8 VDC
24 VDC
20 VDC, minimum
0.1 VDC, maximum
5 to 30 VDC or 5 to 250 VAC
-
-
-
Output Current
Logic 1 signal
Number of output groups
Number of outputs ON (maximum)
Per group - horizontal mounting (maximum)
Per group - vertical mounting (maximum)
Maximum current per common/group
Lamp load
ON state resistance (contact resistance)
Leakage current per point
Surge current
Overload protection
0.75 A
2
16
8
8
6 A
5 W
0.3 Ω
10
µA, maximum
8 A for 100 ms, maximum
No
2.00 A
3
16
4/5/7
4/5/7
10 A
30 W DC/200 W AC
0.2Ω, maximum when new
-
7 A with contacts closed
No
Isolation (Field Side to Logic)
Optical isolation (galvanic)
Isolation resistance
Isolation coil to contact
Isolation between open contacts
In groups of
500 VAC for 1 minute
-
-
-
8 points
-
100 M Ω, minimum when new
1500 VAC for 1 minute
750 VAC for 1 minute
4 points/5 points/7 points
Inductive Load Clamping
Repetitive Energy dissipation
< 0.5 LI
2
x switching rate
Clamp voltage limits
1 W, all channels
L+ minus 48V
-
-
Output Delay
Off to On (Q0.0 and Q0.1)
On to Off (Q0.0 and Q0.1)
Off to On (Q0.2 through Q1.7)
On to Off (Q0.2 through Q1.7)
2 µs, maximum
10
µs, maximum
15
µs, maximum
100
µs, maximum
-
-
-
-
Switching Frequency (Pulse Train
Outputs)
Q0.0 and Q0.1
20 kHz, maximum 1 Hz, maximum
Relay
Switching delay
Lifetime mechanical (no load)
Lifetime contacts at rated load
-
-
-
10 ms, maximum
10,000,000 open/close cycles
100,000 open/close cycles
Cable Length
Unshielded
Shielded
150 m
500 m
150 m
500 m
