10.2 Operating the control panel in STARTER (with the motor rotating)
Creating a Drive Project
10-144
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
Click Assume control priority.
Fig. 10-33 Assuming control priority
2. Click Assume control priority to connect the control panel to the drive interface.
Note the message that is then displayed in the Control priority dialog screen. This note
is very important! (see also Fig. 10-34).
!
Danger
Be cautious when using control priority!
This function is intended exclusively for start-up and diagnosis or within the framework of
maintenance work.
Make sure that the drive is in the “OFF” status and that no ON/OFF1 command has been
issued either by the control word for sequence control or another signal source (e.g. BICO
interconnection).
Once control priority has been transferred to the PC, the BICO interconnections on bit 1 to
bit 6 of the control word are no longer active.
