A.1 List of machine data
Machine and Setting Data 802D
A-198
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
306 G_GROUP2
decimal User-oriented G group for position display immediately 3/7
0 2 1 1000 INTEGER
307 G_GROUP3
decimal User-oriented G group for position display immediately 3/7
0 8 1 1000 INTEGER
308 G_GROUP4
decimal User-oriented G group for position display immediately 3/7
0 9 1 1000 INTEGER
309 G_GROUP5
decimal User-oriented G group for position display immediately 3/7
0 10 1 1000 INTEGER
310 FG_GROUP1
decimal User-oriented G group for position display (external language) immediately 3/7
0 1 1 1000 INTEGER
311 FG_GROUP2
decimal User-oriented G group for position display (external language) immediately 3/7
0 2 1 1000 INTEGER
312 FG_GROUP3
decimal User-oriented G group for position display (external language) immediately 3/7
0 8 1 1000 INTEGER
313 FG_GROUP4
decimal User-oriented G group for position display (external language) immediately 3/7
0 9 1 1000 INTEGER
314 FG_GROUP5
decimal User-oriented G group for position display (external language) immediately 3/7
0 10 1 1000 INTEGER
330 CMM_POS_COORDINATE_SYSTEM
decimal Coordinate position of machine *) immediately 3/7
0 0 0 7 BYTE
*) Explanation:
Both the position and the size of the representation are handed over during initialization. The position of the coordinate system
can be influenced by the parameter “Axis direction” in the header of the file.
The following positions are possible: Position X+ Z+
0 up to the right
1 up to the left
2 down to the right
3 down to the left
4 to the right top
5 to the left up
6 to the right down
7 to the left down
The positions of the elements must be specified in position 4 (mathematic coordinate system). The simulation will then auto-
matically convert the representation to the relevant system.
331 CONTOUR_MASK
decimal Activating the 802 contour definition programming immediately 3/7
0 1 0 1 BYTE
