Siemens SINUMERIK 802D sl Instruction Manual

Machine and Setting Data 802D
A.1 List of machine data
A-213
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
24970 TRANSMIT_BASE_TOOL_2
mm Base tool vector NEW CONF
C07 – DOUBLE
Default 3 0.0, 0.0, 0.0 – – 2/2
27100 ABSBLOCK_FUNCTION_MASK
– Block display parameterized with absolute values POWER ON
N01 – DWORD
Default – 0x0 0 0x1 2/2
27800 TECHNOLOGY_MODE
– Technology in the channel NEW CONF
C09 – BYTE
Default – 0 – – 7/2
plus – 0 – – 2/2
27860 PROCESSTIMER_MODE
– Activating the program runtime measurement RESET
C09 – DWORD
Default – 0x00 0 0x0FF 7/2
plus – 0x07 – – 2/2
27880 PART_COUNTER
– Activate workpiece counter RESET
C09 – DWORD
Default – 0x0 0 0x0FFFF 3/2
27882 PART_COUNTER_MCODE
– Workpiece counting using a user–defined M command POWER ON
C09 – BYTE
Default 3 2, 2, 2 0 99 3/2
28400 MM_ABSBLOCK
– Activate block display with absolute values POWER ON
EXP, C02 – DWORD
Default – 0 – – 2/2
28402 MM_ABSBLOCK_BUFFER_CONF
– Dimension size of upload buffer POWER ON
EXP, C02 – DWORD
Default 2 0, 0 – – 2/2
