A.1 List of machine data
Machine and Setting Data 802D
A-212
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
24855 TRACYL_ROT_AX_FRAME_2
– Rotary axis offset TRACYL 2 NEW CONF
C07 – BYTE
Default – 0 0 2 2/2
24858 TRACYL_DEFAULT_MODE_2
– Selection of the TRACYL mode NEW CONF
C07 – BYTE
Default – 0 0 1 2/2
24860 TRACYL_ROT_SIGN_IS_PLUS_2
– Sign of the rotary axis NEW CONF
C07 – BOOLEAN
Default – TRUE – – 2/2
24870 TRACYL_BASE_TOOL_2
mm Base tool vector NEW CONF
C07 – DOUBLE
Default 3 0.0, 0.0, 0.0 – – 2/2
24900 TRANSMIT_ROT_AX_OFFSET_1
degrees Rotary axis offset TRANSMIT 1 NEW CONF
C07 – DOUBLE
Default – 0.0 – – 2/2
24905 TRANSMIT_ROT_AX_FRAME_1
– Rotary axis offset TRANSMIT 1 NEW CONF
C07 – BYTE
Default – 0 0 2 2/2
24910 TRANSMIT_ROT_SIGN_IS_PLUS_1
– Sign of the rotary axis NEW CONF
C07 – BOOLEAN
Default – TRUE – – 2/2
24911 TRANSMIT_POLE_SIDE_FIX_1
– Limiting of working area in front of / after the pole NEW CONF
C07 – BYTE
Default – 0 0 2 2/2
24920 TRANSMIT_BASE_TOOL_1
mm Base tool vector NEW CONF
C07 – DOUBLE
Default 3 0.0, 0.0, 0.0 – – 2/2
24950 TRANSMIT_ROT_AX_OFFSET_2
degrees Rotary axis offset TRANSMIT 2 NEW CONF
C07 – DOUBLE
Default – 0.0 – – 2/2
24955 TRANSMIT_ROT_AX_FRAME_2
– Rotary axis offset TRANSMIT 2 NEW CONF
C07 – BYTE
Default – 0 0 2 2/2
24960 TRANSMIT_ROT_SIGN_IS_PLUS_2
– Sign of the rotary axis NEW CONF
C07 – BOOLEAN
Default – TRUE – – 2/2
24961 TRANSMIT_POLE_SIDE_FIX_2
– Limitation of the working area in front of/after the pole NEW CONF
C07 – BYTE
Default – 0 0 2 2/2
