Siemens SINUMERIK 802D sl Instruction Manual

Machine and Setting Data 802D
A.1 List of machine data
A-211
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
24120 TRAFO_GEOAX_ASSIGN_TAB_1
– GEO/channel axis assignment for transformation 1 NEW CONF
C07 – BYTE
Default 3 0 0 6 2/2
24130 TRAFO_INCLUDES_TOOL_1
– Tool handling with active 1st transformation NEW CONF
C07 – BOOLEAN
Default – TRUE – – 2/2
24200 TRAFO_TYPE_2
– Transformation 2 in the channel NEW CONF
C07 – DWORD
Default – 0 – – 2/2
24210 TRAFO_AXES_IN_2
– Axis assignment for transformation 2 NEW CONF
C07 – BYTE
Default 20 1, 2, 3, 4, 5, 0 0 6 7/7
plus 6 – – – 2/2
24220 TRAFO_GEOAX_ASSIGN_TAB_2
– GEO/channel axis assignment for transformation 2 NEW CONF
C07 – BYTE
Default 3 0, 0, 0 0 6 2/2
24230 TRAFO_INCLUDES_TOOL_2
– Tool handling with active 2nd transformation NEW CONF
C07 – BOOLEAN
Default – TRUE – – 2/2
24573 TRAFO5_AXIS3_1
– Direction of 3rd rotary axis NEW CONF
C07 – DOUBLE
Default 3 0.0, 0.0, 0.0 – – 7/7
24800 TRACYL_ROT_AX_OFFSET_1
degrees Rotary axis offset TRACYL 1 NEW CONF
C07 – DOUBLE
Default – 0.0 – – 2/2
24805 TRACYL_ROT_AX_FRAME_1
– Rotary axis offset TRACYL 1 NEW CONF
C07 – BYTE
Default – 0 0 2 2/2
24808 TRACYL_DEFAULT_MODE_1
– Selection of the TRACYL mode NEW CONF
C07 – BYTE
Default – 0 0 1 2/2
24810 TRACYL_ROT_SIGN_IS_PLUS_1
– Sign of the rotary axis NEW CONF
C07 – BOOLEAN
Default – TRUE – – 2/2
24820 TRACYL_BASE_TOOL_1
mm Base tool vector NEW CONF
C07 – DOUBLE
Default 3 0.0, 0.0, 0.0 – – 2/2
24850 TRACYL_ROT_AX_OFFSET_2
degrees Rotary axis offset TRACYL 2 NEW CONF
C07 – DOUBLE
Default – 0.0 – – 2/2
