Siemens SINUMERIK 802D sl Instruction Manual

Machine and Setting Data 802D
A.1 List of machine data
A-215
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
30300 IS_ROT_AX
– Rotary axis/spindle POWER ON
–, –, – SCAL, CTEQ BOOLEAN
Default – FALSE – – 2/2
30310 ROT_IS_MODULO
– Modulo conversion for rotary axis/spindle POWER ON
–, –, – CTEQ BOOLEAN
Default – FALSE – – 2/2
30320 DISPLAY_IS_MODULO
– Display modulo 360 degrees for rotary axis POWER ON
–, –, – CTEQ BOOLEAN
Default – FALSE – – 2/2
30350 SIMU_AX_VDI_OUTPUT
– Axis signals for simulation axis POWER ON
–, – CTEQ BOOLEAN
Default – FALSE – – 2/2
30465 AXIS_LANG_SUB_MASK
– Substitution of NC language commands POWER ON
N01 – DWORD
Default – 0 0 3 2/2
30600 FIX_POINT_POS
mm,
degrees
Axis position with G75 POWER ON
–, – – DOUBLE
Default 2 0.0, 0.0 – – 2/2
31000 ENC_IS_LINEAR
– Linear scale POWER ON
–, – – BOOLEAN
Default 1 FALSE – – 2/2
31010 ENC_GRID_POINT_DIST
mm Scale division with linear scales POWER ON
–, – – DOUBLE
Default 1 0.01 – – 2/2
31020 ENC_RESOL
– Encoder lines per revolution POWER ON
–, – – DWORD
Default 1 2048 – – 2/2
31030 LEADSCREW_PITCH
mm Lead of the ballscrew POWER ON
–, – – DOUBLE
Default – 10.0 – – 2/2
31040 ENC_IS_DIRECT
– Encoder mounted directly on the machine POWER ON
–, – – BOOLEAN
Default 1 FALSE – – 2/2
31044 ENC_IS_DIRECT2
– Encoders installed at the attached gearbox NEW CONF
– – BOOLEAN
Default 1 FALSE – – 2/2
31050 DRIVE_AX_RATIO_DENOM
– Load gearbox denominator POWER ON
–, – – DWORD
Default 6 1, 1, 1, 1, 1, 1 1 2147000000 2/2
