Siemens SINUMERIK 802D sl Instruction Manual

A.1 List of machine data
Machine and Setting Data 802D
A-216
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
31060 DRIVE_AX_RATIO_NUMERA
– Load gearbox numerator POWER ON
–, – – DWORD
Default 6 1, 1, 1, 1, 1, 1 –2147000000 2147000000 2/2
31064 DRIVE_AX_RATIO2_DENOM
– Denominator of attached gearbox NEW CONF
– – DWORD
Default – 1 1 2147000000 2/2
31066 DRIVE_AX_RATIO2_NUMERA
– Numerator of attached gearbox NEW CONF
– – DWORD
Default – 1 –2147000000 2147000000 2/2
31070 DRIVE_ENC_RATIO_DENOM
– Measuring gearbox denominator POWER ON
–, – – DWORD
Default 1 1 1 2147000000 2/2
31080 DRIVE_ENC_RATIO_NUMERA
– Measuring gearbox numerator POWER ON
–, – – DWORD
Default 1 1 1 2147000000 2/2
31122 BERO_DELAY_TIME_PLUS
s BERO delay time NEW CONF
–, – – DOUBLE
Default 1 0.000110 – – 2/2
31123 BERO_DELAY_TIME_MINUS
s BERO delay time NEW CONF
–, – – DOUBLE
Default 1 0.000078 – – 2/2
32000 MAX_AX_VELO
mm/min,
rev/min
Maximum axis velocity NEW CONF
–, – CTEQ DOUBLE
Default – 10000. – – 7/2
32010 JOG_VELO_RAPID
mm/min,
rev/min
Rapid traverse in the JOG mode RESET
–, – CTEQ DOUBLE
Default – 10000. – – 7/2
32020 JOG_VELO
mm/min,
rev/min
JOG axis velocity RESET
–, – CTEQ DOUBLE
Default – 2000. – – 7/2
32100 AX_MOTION_DIR
– Traversing direction (not control direction) POWER ON
–, –, – – DWORD
Default – 1 –1 1 2/2
32110 ENC_FEEDBACK_POL
– Sign of actual value (control direction) POWER ON
–, –, – – DWORD
Default 1 1 –1 1 2/2
