Machine and Setting Data 802D
A.2 Setting data
A-229
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
43400 WORKAREA_PLUS_ENABLE
– Working area limitation active in the positive direction IMMED.
– CTEQ BOOLEAN
Default – FALSE – – 7/7
43410 WORKAREA_MINUS_ENABLE
– Working area limitation active in the negative direction IMMED.
– CTEQ BOOLEAN
Default – FALSE – – 7/7
43420 WORKAREA_LIMIT_PLUS
mm,
degrees
Axial working area limitation active in the positive direction IMMED.
– – DOUBLE
Default – 1.0e+8 – – 7/7
43430 WORKAREA_LIMIT_MINUS
mm,
degrees
Axial working area limitation active in the negative direction IMMED.
– – DOUBLE
Default – –1.0e+8 – – 7/7
43500 FIXED_STOP_SWITCH
– Selection “Travel to fixed stop” IMMED.
– – BYTE
Default – 0 0 1 2/2
43510 FIXED_STOP_TORQUE
% Fixed stop clamping torque IMMED.
– – DOUBLE
Default – 5.0 0.0 800.0 2/2
