Siemens SINUMERIK 802D sl Instruction Manual

4.2 MCPA module interfaces
Interfaces
4-30
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
Assignment of the I/O interface connectors
Designation: X1020, X1021
Type: 10-pin connector
Table 4-9 Pin assignment of the connectors X1020 and X1021
Schematic view Pin Name Description
1
1
1
2 DI0 Digital input 0
3 DI1 Digital input 1
4 DI2 Digital input 2
5 DI3 Digital input 3
10
6 DI4 Digital input 4
X1020
10
7 DI5 Digital input 5
X1020
8 DI6 Digital input 6
9 DI7 Digital input 7
10
1
1 P24 24 V DC supply voltage
1
2 Q0 Digital output 0
3 Q1 Digital output 1
4 Q2 Digital output 2
5 Q3 Digital output 3
6 Q4 Digital output 4
10
7 Q5 Digital output 5
X1021
8 Q6 Digital output 6
9 Q7 Digital output 7
10 M Ground (GND)
