Siemens SINUMERIK 802D sl Instruction Manual

Technical Data
8-76
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
Table 8-2 Weights and dimensions, continued
Machine control panel
Dimensions W H D [mm] 170 330 128
Weight [g] approx. 1,500
PP72/48 I/O module
Dimensions W H D [mm] 194 325 35
Weight [g]
S without mounting plate
S with mounting plate
S approx. 300
S approx. 1,200
Digital inputs of the PP72/48 I/O module (to IEC 1131-2/DIN EN 61131-2, type 2 characteristic)
Table 8-3 Digital inputs of the PP72/48 I/O module
Number of inputs
24 each per terminal strip converter
Parameter min. typical max. nominal
Voltage with high level (U
H
)
15 V
1)
30 V
24 V
Input current I
In
at U
H
2 mA – 15 mA
–
Voltage with low level (U
L
)
–30 V – 5 V
0 V
Signal delay time T
PHL
2)
0.5 ms – 3 ms
–
1)
Supply voltage for the digital inputs
Typical output voltage: V
CC
– I
OUT
* R
ON
V
CC
: Current operating voltage (P24OUT
INT
) at X111, X222,
X333: Pin 2
2)
In addition, take into account the PROFIBUS DP communication time and the application cycle time.
A polarity reversal does not cause a high signal level nor does it destroy the inputs.
