System
8.3 SYSTEM - "Machine data" softkeys
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
119
$[LV
8SGDWH
FKDQ
0'
'ULYH
0'
The data of axis 1 are displayed.
Use "Axis +" or "Axis " to switch to the machine area of the next or previous axis.
The contents of the machine data are updated.
Channel-specific machine data
Open the "Channel-specific machine data" window. Use the PageUp / PageDown keys to
browse forward / backward.
Figure 8-10 Channel-specific machine data
SINAMICS drive machine data
Open the "Drive machine data" dialog box.
The first dialog box displays the current configuration, as well as the states of the control,
power supply and drive units.
