Installing/mounting
4.2 Mounting the linear actuator
SIPART PS2 with and without HART
36 Operating Instructions, 10/2013, A5E00074631-11
"Linear actuator IEC 60534 (3 to 35 mm)" mounting kit 6DR4004-8V and 6DR4004-8L
â‘
1
NAMUR mounting bracket
Standardized connection point for mount with fin, column or plane
â‘¡
1 Pick-up bracket Guide the pulley with the carrier pin and rotates the lever arm.
2 Clamping piece Installs the pick-up bracket on the actuator spindle
1 Carrier pin
Installation with pulley
on lever
1 Pulley
Installation with carrier pin
on lever
1 Lever For the range of stroke from 3 mm to 35 mm
The lever 6DR4004–
8L is additionally required for ranges of stroke
> 35 mm to 130 mm (not included in the scope of delivery).
2 U–bolts Only for actuators with columns
⑧
4 Hexagon bolt M8x20 DIN 933–A2
⑨
2 Hexagon bolt
M8x16 DIN 933–A2, torque see the chapter "Technical
specifications > Construction (Page 237)"
6 Spring lock washer A8 - DIN 127–A2
6 Washer B8.4 - DIN 125–A2
â‘«
2 Washer B6.4 - DIN 125–A2
1 Spring VD-115E 0.70 x 11.3 x 32.7 x 3.5
1 Spring lock washer A6 - DIN 137A–A2
1 Lock washer 3.2 - DIN 6799–A2
3 Spring lock washer A6 - DIN 127–A2
3 Socket cap screw M6x25 DIN 7984–A2
1 Hexagon nut M6 - DIN 934–A4
1 Square nut M6 - DIN 557–A4
⑳
4 Hexagon nut M8 - DIN 934–A4
*)
the serial numbers refer to the images of the description of the installation steps below.
