Ionics Instruments 2004 B-2 DLM 30007-08 Rev. A
3. Press CLEAR to return to the Setup menu.
WARNING
Only the factory configured frequency setting should be used for the
820/820AS analyzer. If the frequency setting is changed or the incorrect setting
is selected, the TOC measurements will be in error.
See Appendix A for additional details on menu selections when entering
calibration constants.
CE Mark Compliance
To comply with CE mark standards, additional equipment needs to be
collected for installation of an 820/820AS analyzer. This information is in
addition to the information in the Installation chapter.
Printer and cable (optional) – use CE mark or CISPR class “B” approved
printer; printer cable must be properly shielded.
IBM compatible computer (optional) – use CE mark or CISPR class “B”
approved computer.
RS-232 cable needs to be shielded.
Printer Cable
The 820/820AS analyzer has a 25-pin parallel (Centronics) printer port for the
direct output of results to a printer. If a printer is to be used, connect the
proper shielded cable for the printer to the printer port and secure with screws.
The cable needs to be a shielded printer cable that can be found at computer
stores. The printer must be CE marked and CISPR class “B” approved IBM
compatible. The port must be configured as described.
